Injectors : Ig1 Apache Injector

Home / Products / Injectors / Ig1 Apache Injector

Rail injector for gaseous LPG and Natural Gas. Single version with 0.6 mm stroke. Coils with 2-way built-in watertight connector, compatible with Amp/Delphi. Body made of shaped aluminium and lightened for better heat exchange. Not very sensitive to dirt accumulation, moderate price, easy maintenance and easy to clean. Improved internal flow dynamics.

Patented

WORKING PRESSURE	from 0,5 to 2,0 bar
MAX PRESSURE	3,0 bar
SUPPLY VOLTAGE	10,8 - 14,4 V
INLET GAS FITTING	Rubber hose Ø10mm/Ø12mm/Ø16mm 3/8" / 1/2"
OUTLET GAS FITTING	Calibrated nozzles M8x1
CALIBRATED HOLE RANGE (for nozzles)	1,0 - 3,5 mm (0,25mm step)
T range for LPG	-20 / +120°C
T range for CNG	-40 / +120°C
Approvals	67R-01/110R-00/ISO 15500

1	110R-00 Ext.8
2	67R-01 Ext.7
3	ISO 15500 IG1 Apache Certificate



Nozzle	Connector	Connector	Connector


M5 Sensor	IG1 Connector with temperature sensor	Pressure and Temperature Sensor
